| 产品型号 SUPU ID |
ESF-RS250A70YB3 | ||
| 接线位数 Number of connections |
1 | ||
| 产品层数 Number of rows |
1 | ||
| 电位 Potentials |
1 | ||
| 接线方式 Connection method |
螺钉 |
||
| 防护等级 Protection Level |
IP67 | ||
| 工作温度 Work temperature |
-40℃～+125℃ | ||
| 插拔周期 Insertion/withdrawal cycles |
100 | ||
| 插入力 Insertion force |
≤75N | ||
| 拔出力 Withdrawal force |
≥10N | ||
| 额定电流 Rated Current |
250A |
| 额定电压 Rated Voltage |
1500V DC |
| 过压类别 Overvoltage category |
Ⅲ |
| 污染等级 Pollution degree |
3 |
| 额定冲击电压 Rated impulse voltage |
12.3KV |
| 线缆截面积（AWG） Cable cross-sectional area |
N/A |
| 柔性导线截面积（AWG） Conductor cross section flexible |
50mm² ~70mm² |
| 电缆外径 External cable diameter |
N/A |
| 剥线长度 Stripping length |
N/A |
| 使用组别 Use group |
N/A |
| 额定电流 Rated Current |
250A |
| 额定电压 Rated Voltage |
1500V DC |
| 额定接线容量 Rated cross section |
2/0 AWG |
| 绝缘材料 Insulation material |
PA6 |
| 绝缘材料组别 Insulation material group |
Ⅲ |
| 阻燃等级，符合UL94 Flame retardant grade, UL94 compliance |
V0 |
| 导电体材料 Contact material |
T2 |
| 导电体表面镀层 Surface characteristics |
Ag,Plated |
| 认证图标 Certificate |
  |
||
| UL证书号 UL file No. |
|||
| VDE证书号 VDE No. |
|||
| TUV证书号 TUV No. |
|||
| 包装信息 Packaging information |
|||
