产品型号 |
MC-PJ5.08HXXP-B-0001 |
||
| 产品间距 Pitch |
5.08mm | ||
| 产品层数 Number of levels |
1 | ||
| 产品位数 Number of connections |
2P-24P | ||
| 接线方式 Connection method |
直插弹簧接线 | ||
| 防护等级 Protection Level |
IP20 | ||
| 工作温度 Work temperature |
-40~+105℃ | ||
| 额定电流 Rated Current |
12A | ||
| 额定电压 Rated Voltage |
320V | ||
| 过压类别 Overvoltage category |
Ⅲ | Ⅲ | Ⅱ |
| 污染等级 Pollution degree |
3 | 2 | 2 |
| 额定冲击电压 Rated impulse voltage |
4KV | 320KV | 2.5KV |
| 额定电压 Rated Voltage |
250V | 320V | 630V |
| 硬导线截面积 Conductor cross section solid |
0.2-2.5mm² | ||
| 柔性导线截面积 Conductor cross section flexible |
0.2-2.5mm² | ||
| 柔性导线截面积，带绝缘管套 Conductor cross section flexible,with furrule |
- | ||
| 锁线螺钉规格 Locking screw Specification |
- | ||
| 额定扭矩 Rated Torque |
- | ||
| 固定螺钉规格 Fixed Screw Specification |
- | ||
| 额定扭矩 Rated Torque |
- | ||
| 剥线长度 Stripping length |
7-8mm | ||
| 使用组别 Use group |
B |
C |
D |
| 额定电流 Rated Current |
10A |
- | 10A |
| 额定电压 Rated Voltage |
300V |
- | 300V |
| 额定接线容量 Rated cross section |
24-12AWG | ||
| 绝缘材料 Insulation material |
PA66 |
| 绝缘材料组别 Insulation material group |
Ⅰ |
| 阻燃等级，符合UL94 Flame retardant grade, UL94 compliance |
V0 |
| 导电体材料 Contact material |
Copper alloy |
| 导电体表面镀层 Surface characteristics |
Sn,Plated |
| 认证图标 Certificate |
  |
||
| UL证书号 UL file No. |
|||
| VDE证书号 VDE No. |
|||
| TUV证书号 TUV No. |
|||
| 包装信息 Packaging information |
25pc | ||
